Genset Cummins Diesel Genset Cummins 6BT5.9-G1 100 Kva

Introduction - For Your Need To Know


Engine  Cummins 6BT5.9-G1 - Is The Part of Cummins 6 BT family Engine Series, 6 BT series Have 3 Series ; 6BT5.9 ; 5.9 Liter\5900 Cc - Turbocharged Without Aftercooled ; 6 BTA5.9 ; 5900 Liter\5900 Cc - Turbocharged - With Aftercooled ; 6BTAA ; 5.900 Liter\5.900 Cc - Turbocharged Air To Air Chargedcooled.


Genset Cummins 6BT5.9-G1 100 Kva have been formulated to ensure proper application of generator drive engines in Cummins corporate generator set installations. Genset Cummins 6BT5.9-G1 100 Kva drive engines are not designed for and shall not be used in variable speed D.C. generator set applications Applicable for supplying emergency power for the duration of the utility power outage. No overload capability is available for this standby rating. Under no condition is an engine allowed to operate in parallel with the public utility at the Emergency Standby Power rating. This rating should be applied where reliable utility power is available. An emergency standby rated engine should be sized for a maximum of an70% typical load factor and 200 hours of operation per year. This includes a maximum of 1 hour in a 12 hour period at the Emergency Standby Power rating. Emergency Standby rating should never be applied except in true emergency power outages. Negotiated power outages contracted with a util-ity company are not considered an emergency. These Diesel Engine 6BT5.9-G1 have A 92 Kwm@RPM 1500 ( Gross Engine Output at Peak Power ).


Genset Cummins 6BT5.9-G1  100 Kva water cooled Diesel engine,
Oil and fuel filter fitted, water separator
 Lube-oil drain valve fitted
Electric starter & Charge alternator 12 v D.C
Mechanical governor
Normal duty air filter
Single bearing alternator, class H/H
Standard voltage 400/230 volts 50 Hz
Exciter/Voltage reg - Torque Match as standard
PCC1301 as standard
Steel base frame with A/V mounting,
Engine, Alternator, Chassis & Control Box
Munsell Jade Green
Radiator
Packing under shrunk plastic film
Genset Cummins 6BT5.9-G1  100 Kva Operation & Maintenance manual
Standard set of labels


Description:

Introduction -


For your information, Diesel Generator Set ( Genset ) Cummins ini Menggunakan Type Engine 6BT5.9-G1 , Dengan Configurasi 6 cylinder inline Engine. Seri dan type Engine Cummins 6BT5.9-G2 adalah bagian dari 6 ( Six Series ) Family Engine Cummins yg terdiri 3 Type Engine dan 8 Varian Engine Yaitu : 6 BT Series ; 5.9 liter\5.900cc ; ( 6BT - Turbocharged - 6BTA - Turbocharged Aftercooled and  6BTAA - Turbocharged Air-to-air Chargedcooled), 6 CT ; 8.3 liter\8.300cc ;  ( 6 CTA - Turbocharged - dan 6 CTAA - Turbocharged Air-to-air charged Cooled ), 6LTAA Series-Turbocharged Air-to-air chargedcooled ; 8.9 liter\8.900cc Dengan Output Power yg Berbeda-beda. Engine 6BT5.9-G1 ini adalah salah  Satu Type Engine dari Cummins yg sangat Handal, Efissien dan Compact dan di lengkapi dengan Turbocharged,  Sehingga Kehandalannya ini Sungguh Sangat di akui Oleh Competitornya. Salah Satu Ciri Engine Cummins yg tangguh ini Terbukti Ketika Engine Ini di Beban Pada Peak Power ( 100%) dengan Durasi yg Cukup Lama Tanpa Terjadi Sesuatu. Sehingga Engine Cummins Terkenal Sebagai Engine Heavy Duty. Meskipun Engine ini belum Memenuhi Regulasi Uji Emisi Euro. Akan Tetapi Justru Engine ini Lebih Mudah dan Sangat Simple Perawatannya Sehingga Sangat Menguntungkan Bagi Penggunanya salah satu contohnya adalah ; Untuk Wilayah\Teritori di mana Kualitas BBM-nya Tidak harus Mensyaratkan Dengan Menggunakan Kadar Cetane tinggi dan Sulfur yg Rendah Maka Engine cummins ini pun masih mampu untuk mengkonsumsi Fuel ( Solar ) Dengan tingkat sulfur yg Tinggi ( Masih mampu mengkonsumsi Solar dengan Kualitas yg kurang Bagus ).


Generator Set ini Di Coupled Dengan alternator Stamford. Salah Satu Perusahaan yg Membuat alternator Ternama yang berasal dari Inggris yg Memiliki Reputasi Kelas Dunia yg Sangat Teruji Kehandalannya.





Spec and Data Sheet :


Engine type 6BT5.9-G1 ; Turbo Charged ; 6 cylinder inline ; Direct Injection ; 4 Stroke ; Bore x Stroke 102 x 120 mm ; Displacement 5.9  Liter/5.900 cc ; Compression Ratio 17.3 : 1 ; Oil Capacity 16.4 Liter ; Generator Stamford, 1500 Rpm, 50 Hz, 220/380 Volt, 3 Phase, Pf 0,8 dengan kapasitas 100 Kva Prime rating atau 80 Kw Prime Rating.


Scoupe Of Supply :


Digital control panel by deepsea or Similar, MCCB, muffler, flexible muffler, daily tank, battery with cable battery, Certificate Of Origin, Manual Book.


Warranty :


Garansi 1 tahun / 2000 jam operasi mana yang tercapai terlebih dahulu dan semua unit yg kami delivery sudah dilakukan test loadbank Di Workshop sebagai Standard Operasional Prosedure.




Harga :







Detail Price and Specification By Requested
